Not every finish defect is a painter problem. A meaningful share of dirt nibs, orange peel, fisheyes, and film-thickness issues trace back to something in the booth environment — wrong filter, worn media, airflow imbalance, contaminated intake, or install error. This diagnostic hub walks the six most common defects, likely booth-side causes, and what to check first.
Dirt nibs / seeds in the finish
What you see: raised specks in the clear or basecoat that need sanding out. Random pattern, not localized.
Likely booth-side causes, in order:
- Intake / ceiling filter loaded or damaged. When ceiling media loads up or tears, unfiltered air drops into the booth carrying shop dust. Check pressure drop and inspect for tears, sagging, or gapping around the frame.
- "Wrong-side-out" install on directional media. Tackified ceiling filters have a sticky side that faces AWAY from the booth (toward the plenum). Installing them backwards means the tack is capturing dust from the wrong side and the un-tacky side is shedding fibers into the booth. This is the single most common preventable dirt-nib cause we see.
- Exhaust filter overloaded. When exhaust filters clog, cross-flow patterns change, dust from prep area migrates into the booth. Change on pressure drop, not on calendar.
- Booth seals compromised. Torn door seals or worn perimeter sweeps let dirty shop air infiltrate under the positive-pressure boundary.
- Painter's suit shedding. Paper coveralls at end of life. Not a booth problem but often blamed on the booth first.
First check: pressure drop across the ceiling filter. If +0.5" w.c. (or +0.25" in SCAQMD regions) over baseline, change now. Then inspect for install orientation.
Orange peel
What you see: textured surface that looks like the skin of an orange. Not smooth, not glossy.
Booth-side causes (most orange peel is spray-technique, but the booth can contribute):
- Airflow velocity too high. If downdraft velocity exceeds spec (typically 50 FPM downdraft, 100 FPM crossflow), atomized paint dries in-flight before it flows out. Verify with a hot-wire anemometer at the operator's shoulder height.
- Ambient temperature too high. Booth make-up air heater running hot, or hot ambient in summer. Solvent flash-off is too fast for the coating to flow.
- Exhaust starving intake. Blocked or overloaded exhaust filters can cause the intake to accelerate to compensate, raising velocity beyond spec.
First check: booth velocity at the paint zone. Then verify make-up air temperature at the ceiling.
Fisheyes / cratering
What you see: circular voids in the finish, usually with a raised rim. Look like eyes.
Root cause is silicone contamination. The booth-side culprits:
- Compressed-air contamination. Silicone-based lubricants downstream of the compressor migrate into spray air. Check air-line filters, water separators, and any lubricant used in the air system.
- Silicone-based tire dressings, glass cleaners, or polishes used in the shop area upstream of the intake filter. Aerosolized silicone gets into the booth make-up air, deposits on the panel, contaminates the coating.
- Wax or grease-and-wax remover contamination from the prep bay if intake pulls from that area.
First check: ban silicone products from the shop. Add coalescing filter + silicone-scavenging cartridge to compressed-air feed. Wipe with wax-and-grease remover between coats.
Sags and runs
What you see: paint slid downward before curing, leaving a raised drip or wave.
Booth-side causes:
- Airflow velocity too LOW. Opposite problem from orange peel. Solvent doesn't flash-off, film stays wet, gravity takes over. Check for clogged exhaust filters restricting overall airflow.
- Booth temperature too low. Painting in an unheated booth in winter is a classic sag generator.
- Ambient humidity high. Blocks solvent evaporation. Add dehumidification or wait for a drier day on humidity-sensitive coatings.
Overspray on the vehicle
What you see: gritty, textured surface on panels the painter wasn't targeting. Cleans off but shouldn't be there.
Booth-side causes:
- Exhaust filter loaded / airflow reversal. Overspray isn't being pulled to the exhaust wall; it recirculates and lands on the vehicle. Change exhaust filters.
- Crossflow instead of downdraft. Older or improperly-serviced booths sometimes lose their downdraft pattern when ceiling filters block up or the intake fan degrades.
- Booth door open during spray. Kills the pressure boundary and creates local eddies.
Film thickness inconsistency
What you see: different mil readings across a panel or between panels shot in the same session.
Booth-side contributors (again, mostly spray technique, but):
- Uneven airflow zones. If ceiling filter loading is uneven — for example, half the filters are new and half are loaded — you get velocity variation across the booth. Change filters in complete sets, not spot-replace.
- Contaminated compressed air. Water or oil pulses in the line change pattern and material flow at the gun.
The universal first check: pressure drop
A Magnehelic gauge on the ceiling filter is the single best diagnostic tool in the booth. It tells you when to change filters (before defects show up), it tells you when the exhaust side is starving intake, and it gives you a baseline to spot slow changes. If you don't have one installed, that's step one. See our MERV vs. 98% capture guide for the compliance side.
Still troubleshooting?
Our team runs a booth service business as well as this shop. If you're chasing a defect and want a second opinion, call (800) 381-0149. We can usually narrow it down over the phone with a few questions about your booth model, filter type, and change-out cadence.
