Many shops put painters in supplied-air respirators for spraying isocyanate clears and other high-hazard coatings. But the respirator is only as safe as the air feeding it. If that air comes from your shop compressor, it carries everything the compressor does, and OSHA sets specific limits on what's allowed.
This guide summarizes OSHA's breathing air requirements from 29 CFR 1910.134(i), explains how they apply to a shop compressor, and shows how a dedicated breathing air system is built to meet them. It's general information, not legal or safety advice. Confirm your own program with a qualified safety professional.
Grade D: the air quality standard
OSHA requires compressed breathing air to meet at least Grade D as defined by the Compressed Gas Association (ANSI/CGA G-7.1). The key limits:
| Component | Grade D requirement |
|---|---|
| Oxygen | 19.5–23.5% |
| Condensed hydrocarbons (oil) | 5 mg/m³ or less |
| Carbon monoxide (CO) | 10 ppm or less |
| Carbon dioxide (CO₂) | 1,000 ppm or less |
| Odor | No noticeable odor |
Oil and carbon monoxide are the two that catch shops out. Oil carries over from the compressor. CO can be drawn in at the compressor intake, or produced inside an oil-lubricated compressor that runs hot.
What OSHA requires of a breathing air compressor
When breathing air comes from a compressor, 1910.134(i) adds requirements for the compressor itself:
- Clean intake. The compressor must be set up to prevent contaminated air from entering the supply. Watch for engine exhaust, vehicle bays and spray booth exhaust near the intake.
- Dry air. Moisture must be kept low enough that the dew point at 1 atmosphere is at least 10°F below the ambient temperature.
- Sorbent beds and filters. Suitable in-line air-purifying sorbent beds and filters must be installed to further assure breathing air quality, and maintained or replaced according to the manufacturer's instructions.
- A dated tag. A tag at the compressor must show the most recent change date and the signature of the person authorized to make the change.
- CO protection for oil-lubricated compressors. These need a high-temperature alarm, a carbon monoxide alarm, or both. If you rely on a high-temperature alarm only, the air must be monitored often enough to keep CO at or below 10 ppm. Non-oil-lubricated compressors must also keep CO at 10 ppm or less.
- Dedicated couplings. Breathing air couplings must be incompatible with outlets for other gas systems or non-breathable air, so no one can plug a respirator into the tool air line by mistake.
Breathing air quality is one part of 1910.134. The full standard also covers a written respiratory protection program, medical evaluation, fit and training, and NIOSH-approved respirators. The respirator, hose and air system have to work together.
How a breathing air system meets those requirements
A dedicated breathing air system sits between your compressor and your painters and handles the filtration and monitoring in one assembly. RTi's BRAD line is a good example of how one is put together.
BRAD-BD1: breathing air for one or two operators
RTi's BRAD-BD1 is rated for up to 60 SCFM and one to two operators. According to RTi it includes:
- A deep-bed activated carbon pre-filter that removes hydrocarbons to 0.003 ppm.
- A 0.01-micron final filter for fine particulate and oil, at 99.9998% efficiency.
- A CO monitor preset to alarm at 10 ppm, matching the Grade D limit, with a bar graph display and a low-pressure alarm.
- A high-flow regulator and dual ½" outlets with quick disconnects, mounted on a board for installation.
Masks and hose are sold separately as operator kits: a NIOSH-approved full-face (BRAD-M1C) or flip-up (BRAD-M2C) mask, 35 feet of non-gassing breathing air hose and a flow control valve on a belt.
BRAD-PERF: paint air and breathing air in one
For booths that also need -40°F paint air, the BRAD-PERF-25C (one gun) and BRAD-PERF-50C (two guns) combine a Perfect Air® desiccant paint air system with a breathing air pre-filter and an inline CO monitor that displays actual CO levels and alarms at 10 ppm. One installation supplies both the gun and the painter. See why waterborne paint needs truly dry air for the paint air side.
Keeping breathing air compliant day to day
- Change elements on the manufacturer's schedule. OSHA ties sorbent beds and filters to the manufacturer's instructions. For the BRAD-BD1, RTi calls for the carbon element (4P-060) every 3 months and the coalescer (3C-061) every 6 months. Our element change schedule lists every unit.
- Tag every change with the date and the signature of the person who made it.
- Calibrate and test the CO monitor on the manufacturer's schedule, and never bypass an alarm.
- Keep breathing air hose separate from paint and tool hose, with dedicated couplings.
- Re-check the compressor intake whenever the shop layout changes.
Frequently asked questions
What is Grade D breathing air?
Grade D is the compressed breathing air standard from the Compressed Gas Association (ANSI/CGA G-7.1) that OSHA requires for supplied-air respirators. It limits carbon monoxide to 10 ppm, carbon dioxide to 1,000 ppm and condensed hydrocarbons to 5 mg/m³, requires 19.5–23.5% oxygen, and allows no noticeable odor.
Does an oil-lubricated compressor need a CO monitor for breathing air?
Under OSHA 1910.134(i)(7), an oil-lubricated compressor used for breathing air needs a high-temperature alarm, a carbon monoxide alarm, or both. If only a high-temperature alarm is used, the air must be monitored often enough to keep CO at or below 10 ppm.
Can I use my shop air compressor for breathing air?
It can be done, but the air must meet Grade D and the compressor setup must meet OSHA 1910.134(i): a clean intake, dry air, in-line sorbent beds and filters maintained to the manufacturer's schedule, a dated change tag and CO protection. A dedicated breathing air system with a CO monitor handles the filtration and monitoring. Confirm your setup with a safety professional.
How often should breathing air filters be changed?
OSHA requires breathing air filters and sorbent beds to be maintained and replaced according to the manufacturer's instructions. For RTi's BRAD-BD1, that's the 4P-060 carbon element every 3 months and the 3C-061 coalescing element every 6 months.
Do breathing air hoses need special couplings?
Yes. OSHA requires breathing air couplings to be incompatible with outlets for non-breathable air or other gas systems, so a respirator can't be connected to a tool air line by mistake.
Plan your breathing air system with us
Tell us how many painters you're supplying, what compressor you run and whether you also need paint air, and we'll help you lay out the right RTi BRAD system, masks and hose. Full technical sheets for every BRAD unit are on rti-pbe.com. This article summarizes 29 CFR 1910.134(i); read the full standard on osha.gov and confirm your program with a qualified safety professional.
