Purpose-built for USI Italia spray booths, this M5-grade (formerly F5) tackified polyester ceiling filter is cut to fit the standard ceiling banks of the Chronotech flagship (Dynamic and Supremacy), the waterborne-optimized Master series, and Cargo configurations for truck and industrial work. USI Italia's Chronotech Supremacy is the paint booth of choice for Ferrari, Red Bull Racing, Mercedes AMG Petronas, and Alpine F1, so the ceiling intake spec matters.

Key Features

96% average arrestance, M5 under EN 779:2012 (the class formerly called F5), stopping dust before it reaches the finish.
600 g/m² media, 22 mm (±3) thick, with 820 g/m² dust holding capacity in testing.
Multi-layer construction with a fine mesh backing on the clean-air side.
Impregnated tackifier throughout bonds paint particles to the media instead of releasing them downstream.
UL 900 Class 2 and DIN 53438-F1 flame rating, rated to 120 °C (248 °F).
Rated for 0.25 m/s face velocity, matched to booth ceiling-plenum airflow.
Cut to standard USI Italia ceiling-bank sizes for a drop-in fit, with custom sizes available for non-standard banks.

Best For

Automotive collision and refinish
Formula 1, motorsport, and concours-quality refinishing
OEM dealership reconditioning
Light industrial and composite finishing
Any USI Italia booth that needs M5 (formerly F5) or EU5-grade ceiling intake filtration

Usage & Care

USI Italia publishes no fixed interval; its booth controls count run hours and read pressure. Booth makers that publish a figure put ceiling filters at about 1,000 to 1,200 operating hours. The media is rated to a 450 Pa (1.81 in. w.g.) final pressure drop. Chronotech and Master booths running high-throughput waterborne cycles reach those hours fastest, so change on hours and pressure to preserve drying-cycle consistency. The DGT Manager software on equipped booths surfaces pressure-differential changes early, so you can change filters before airflow is compromised.

Test Data

M5 under EN 779:2012 (the class formerly called F5): 96% average arrestance, initial pressure drop under 30 Pa (0.12 in. w.g.) at 0.25 m/s, change at 450 Pa (1.81 in. w.g.), 820 g/m² dust holding capacity, rated to 120 °C (248 °F). Flame rating DIN 53438-F1 and UL 900 Class 2. Manufacturer test, April 2025.
