Custom Cut Paint Booth Ceiling Filter Blanket – M5 Tackified Polyester – Any Size, Any Booth

Get the exact fit your spray booth demands with no waste. Our Custom Cut Ceiling Filter Blanket is the same M5-grade (formerly F5) tackified polyester media we use across our brand-specific blankets, cut to your specifications for booths with non-standard ceiling-bank dimensions, legacy installations the OEM no longer supports, or shops running custom-fabricated paint enclosures.

Minimum cut size: 24 × 24 inches. Custom cuts smaller than 24 inches in either dimension cannot be produced from our stock roll.

Key Features

• 96% average arrestance, M5 under EN 779:2012 (the class formerly called F5), stopping dust before it reaches the finish.
• 600 g/m² media, 22 mm (±3) thick, with 820 g/m² dust holding capacity in testing.
• Multi-layer construction with a fine mesh backing on the clean-air side.
• Impregnated tackifier throughout bonds paint particles to the media instead of releasing them downstream.
• UL 900 Class 2 and DIN 53438-F1 flame rating, rated to 120 °C (248 °F).
• Rated for 0.25 m/s face velocity, matched to booth ceiling-plenum airflow.
• Cut to any size from 24 × 24 inches and up for booths that standard blankets do not fit.

Best For

• Non-standard booth dimensions on custom-fabricated or owner-modified booths
• Legacy installations where the original OEM size is no longer offered (Spraybake, Binks, DeVilbiss, older imports)
• Industrial enclosures for aerospace, marine, or production-line painting
• Specialty applications such as woodworking booths, furniture finishing, sign painting, and custom motorcycle work
• Any installation where the standard sizes from our brand-specific catalog do not fit

Already Stock Your Size?

Before ordering custom, check our pre-cut brand-specific blankets. We may already stock your exact size:

• Accudraft (TITAN, ITALIA, MX Series)
• Garmat (3000, Tier 1, Chinook, Frontier)
• GFS (Ultra and Performer Series)
• Blowtherm (Extra, Ultra 2000, World Series)
• USI Italia (Chronotech, Master)
• Nova Verta (Prestige, Raptor Series)
• Eagle (Crossflow and Downdraft)
• Spraybake (legacy UK and Canada)
• Binks (legacy replacement)
• DeVilbiss (legacy and Concept Cure)

Test Data

M5 under EN 779:2012 (the class formerly called F5): 96% average arrestance, initial pressure drop under 30 Pa (0.12 in. w.g.) at 0.25 m/s, change at 450 Pa (1.81 in. w.g.), 820 g/m² dust holding capacity, rated to 120 °C (248 °F). Flame rating DIN 53438-F1 and UL 900 Class 2. Manufacturer test, April 2025.

Download the spec sheet (PDF)
